Backup lamps circuit, hybrid for Kia Optima III (2010-2013)
Backup lamps circuit, hybrid
25 CHG-A POSITION SW
A/V, NAVIGATION HEAD UNIT
AUDIO
B/UP LP FUSE
BACK UP LAMP
BCM (LOWER CENTER OF DASH)
BLK WIRE
BLU WIRE
BRN WIRE
E/R FUSE, RELAY BOX
ELECTRO- CHROMIC MIRROR
GRN WIRE
GRY WIRE
HOT IN ON OR START
LEFT REAR COMBINATION LAMP (IN)
NCA WIRE
ORG/ WIRE
PCM (LEFT SIDE OF ENGINE COMPT)
PNK ON/START INPUT WIRE
PNK WIRE
POSITION SW
RED WIRE
RED/BLK WIRE
RIGHT REAR COMBINATION LAMP (IN)
SIG (1)
SIG (2)
SIG 3
SIG 4
TCU 2 FUSE
TRANSAXLE RANGE SWITCH (TOP OF TRANSAXLE ASSEMBLY)
W/ NAVIGATION
W/ UVO AUDIO
W/O NAVIGATION
