Wiring diagram engine performance 2.4l hybrid, virtual engine sound system circuit for Kia Optima III (2010-2013)

Wiring diagram engine performance 2.4l hybrid, virtual engine sound system circuit

Get access

ACC/ON INPUT BLK WIRE BLU WIRE C-CAN HIGH C-CAN LOW CLOCK FUSE COMPUTER DATA LINES SYSTEM HOT AT ALL TIMES HOT IN ACC OR ON I/P JUNCTION BOX I/P-E MEMORY POWER MODULE 3 FUSE NCA WIRE ORG/ WIRE RED WIRE VESS SPEAKER VESS UNIT VESS VESS SPEAKER SPEAKER (+) (-) WHT WIRE YEL WIRE
