Kia Optima III (2010-2013) stop smart lamp key control relay module Wiring diagram
This page shows the only wiring diagram for the component.stop smart lamp key control relay module, which is found in the car Kia Optima III (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram stop smart lamp key control relay module (1 of 1)
ACTIVE AIR FLAP
AHB 1 FUSE
ALT FUSE
B/UP LP FUSE
BATTERY
BATTERY, BATTERY FUSE BOX
BCM
BLK RED/ WIRE
BLK WIRE
BLOWER RELAY
BLU WIRE
BRN WIRE
C/FAN HI RELAY OPCU RELAY
C/FAN LO FUSE
C/FAN LO RELAY
CHG-A
CHG-K
DEICER FUSE
DEICER RELAY
E/R FUSE, RELAY BOX
ELECTRIC LOW VOLTAGE BMS BLOWER OIL PUMP DC-DC CONVERTER MOTOR RELAY UNIT
ELECTRIC OIL PUMP UNIT
EPS CONTROL
ESC 1 FUSE
ESC 2 FUSE
ESC 3 FUSE
ESC MODULE
FROM I/P JUNCTION BOX (DIAGRAM 2 OF 6) TO OPCU RELAY (DIAGRAM 1 OF 6)
FROM IGN 1
FROM MDPS FUSE (DIAGRAM 1 OF 6)
FROM OCPU 2 FUSE (DIAGRAM 1 OF 6)
FUSE (DIAGRAM 1 OF 6)
GRN WIRE
GRY WIRE
HAC RELAY
HCU FUSE
HYBRID CONTROL
HYBRID POWER CONTROL UNIT
HYDRAULIC POWER
IGN 2 MDPS FUSE FUSE
IP B+1 BLOWER FUSE FUSE
IP B+2 FUSE
IP B+3 AHB 2 EMS FUSE FUSE FUSE
LOW VOLTAGE DC-DC CONVERTER
MCU
MODULE
MULTI FUSE
MULTIPURPOSE CHECK CONNECTOR
OPCU 1 FUSE
ORG/ WIRE
PCM
PCM TRANSAXLE RANGE SWITCH
PNK BMS INVERTER C/FAN FUSE OPCU 2 FUSE FUSE WIRE
PNK WIRE
PNK/BLK WIRE
RED WIRE
RR HTD FUSE
RR HTD RELAY
STOP LAMP SWITCH
STOP LP FUSE
STOP SMART LAMP KEY CONTROL RELAY MODULE
TCU 1 FUSE
TCU 2 ECU 4 FUSE FUSE
TO FUSE, RELAY BOX (DIAGRAM 2 OF 6)
TO I/P JUNCTION BOX (DIAGRAM 3 OF 6)
TO I/P JUNCTION BOX (DIAGRAM 5 OF 6) ESC MODULE
TO INVERTER FUSE IGN 1 (DIAGRAM 1 OF 6) FUSE
TO STOP LP FUSE (DIAGRAM 1 OF 6)
UNIT)
W/ W/O NAVI NAVI
WATER PUMP FUSE
WATER PUMP RELAY
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit, hybrid (1 of 6) -> STOP SMART LAMP KEY CONTROL RELAY MODULE
