Kia Optima III (2010-2013) steering angle signal Wiring diagram
This page shows the only wiring diagram for the component.steering angle signal, which is found in the car Kia Optima III (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram steering angle signal (1 of 1)
29 30 HIGH LOW
31 32 LOW HIGH
7 8 C-CAN HIGH C-CAN LOW
AHB 1 FUSE
AHB 2 FUSE ESC 2 FUSE
B-CAN TRANSCEIVER
BCM (LOWER CENTER OF DASH)
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BRN WIRE
C-CAN TRANSCEIVER
CHG-A
CLOSE WITH BRAKE PEDAL DEPRESSED
COMPUTER DATA LINES SYSTEM
DRIVER DOOR SWITCH
E/R FUSE, RELAY BOX MULTI FUSE
EPS CONTROL MODULE (LEFT CENTER OF DASH)
ESC 1 FUSE
ESC 3 FUSE
ESC OFF BRAKE IND ABS IND ESC IND IND
GRN WIRE
GRN/ORG WIRE
GRY WIRE
HAC RELAY
HOT AT ALL TIMES
HOT IN ON OR START
HYBRID CONTROL UNIT
HYBRID FUSE, REALY BOX
INSTRUMENT CLUSTER
IPS 4 5
LEFT FRONT WHEEL SENSOR (ON LEFT FRONT STEERING KNUCKLE)
LEFT REAR WHEEL SENSOR (BASE OF LEFT "C" PILLAR)
MCU
NCA WIRE
OPEN WITH BRAKE PEDAL DEPRESSED
ORG/ WIRE
ORG/BLK WIRE
PCM (LEFT SIDE OF ENGINE COMPT)
PNK WIRE
PNK/BLK WIRE
RED WIRE
RIGHT FRONT WHEEL SENSOR (ON RIGHT FRONT STEERING KNUCKLE)
RIGHT REAR WHEEL SENSOR (BASE OF RIGHT "C" PILLAR)
SMART KEY CONTROL MODULE (UNDER RIGHT SIDE OF DASH)
STEERING ANGLE SIGNAL
STOP LAMP RELAY
STOP LAMP SWITCH
STOP LP FUSE
WHT WIRE
WHT/ORG WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Anti-lock brakes circuit, hybrid (2 of 2) -> STEERING ANGLE SIGNAL
