Kia Optima III (2010-2013) ssb ill ground wiring diagram
This page shows the only wiring diagram for the component.ssb ill ground, which is found in the car Kia Optima III (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
ssb ill ground wiring diagram (1 of 1)
B+(ILL+)
BATT ILL(+)
BCM (LOWER CENTER (LEFT "B" OF DASH) PILLAR)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
DEMODULATOR
DRIVER SMART KEY OUTSIDE HANDLE (DRIVER'S DOOR)
FOB HOLDER
GRY WIRE
GRY/BLK WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
I/P JUNCTION BOX
I/P-E
ILL
KEY IN SW
NCA WIRE
ORG/ WIRE
OUTSIDE HANDLE (PASSENGER'S DOOR)
PASSENGER SMART KEY
PDM 2 FUSE
POWER DISTRIBUTION SYSTEM
RED WIRE
SSB AMBER
SSB GREEN
SSB ILL GROUND
SSB ILL POWER
SSB SW 1
SSB SW 2
STOP BUTTON SWITCH
WHT WIRE
WHT/ORG WIRE
YEL WIRE
YEL/BLK WIRE
YEL/ORG WIRE
Go to component -> Immobilizer circuit, except hybrid with smart key system (2 of 3) -> SSB ILL GROUND
