Kia Optima III (2010-2013) right head lamp leveling device actuator Wiring diagram
This page shows the only wiring diagram for the component.right head lamp leveling device actuator, which is found in the car Kia Optima III (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right head lamp leveling device actuator (1 of 1)
ARISU 2
ARISU 2 CONTROL
AUTO HEAD LAMP LEVELING DEVICE MODULE
B-CAN
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SYSTEM
E/R FUSE, RELAY BOX (LEFT SIDE OF ENGINE COMPT)
GRN WIRE
HEADLAMPS CIRCUIT
HOT AT ALL TIMES
HOT IN ON OR START
I/P JUNCTION BOX
I/P-B
I/P-C
I/P-D
I/P-D I/P-E
IP B+2 FUSE
IPS CONTROL MODULE
LEFT HEAD LAMP LEVELING DEVICE ACTUATOR (LEFT HEADLIGHT ASSEMBLY)
MODULE 1 FUSE
MULTI FUSE
ORG/ WIRE
PNK PNK WIRE
PNK WIRE
RED WIRE
RIGHT HEAD LAMP LEVELING DEVICE ACTUATOR
RIGHT HEADLIGHT ASSEMBLY
W/ HYBRID
WHT/ORG WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Auto headlamps leveling system (ahls) circuit -> RIGHT HEAD LAMP LEVELING DEVICE ACTUATOR
