Kia Optima III (2010-2013) pnk on/start input Wiring diagrams
This page contains all the electrical diagrams for the component. pnk on/start input, in which he is found in the car Kia Optima III (2010-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram pnk on/start input (1 of 2)
8 CHG-AG CHTG-AG POSITION SW 2.4L 2.0L
A/T
A/V, NAVIGATION HEAD UNIT
AUDIO
B/UP LP FUSE
BACK UP LAMP
BACK-UP LAMP SWITCH (ON TOP OF TRANSAXLE)
BCM (LOWER CENTER OF DASH)
BLK WIRE
BLU (OR BLU/ORG) WIRE
BLU (OR BRN) WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
BRN/ORG WIRE
ELECTRO- CHROMIC MIRROR
ENGINE ROOM RELAY BOX
GRN WIRE
HOT IN ON OR START
LEFT REAR COMBINATION LAMP (IN)
M/T
NCA WIRE
ORG/ WIRE
PCM (LEFT SIDE OF ENGINE COMPT)
PNK ON/START INPUT WIRE
PNK WIRE
POSITION SW
RED WIRE
RED/BLK WIRE
RIGHT REAR COMBINATION LAMP (IN)
SIG (1)
SIG (2)
SIG 3
SIG 4
TCU 2 FUSE
TRANSAXLE RANGE SWITCH (TOP OF TRANSAXLE ASSEMBLY)
W/ BRISTOL AUDIO
W/ NAVIGATION
W/O NAVIGATION
WHT/ORG WIRE
Go to component -> Backup lamps circuit, except hybrid -> PNK ON/START INPUT WIRE
Wiring diagram pnk on/start input (2 of 2)
25 CHG-A POSITION SW
A/V, NAVIGATION HEAD UNIT
AUDIO
B/UP LP FUSE
BACK UP LAMP
BCM (LOWER CENTER OF DASH)
BLK WIRE
BLU WIRE
BRN WIRE
E/R FUSE, RELAY BOX
ELECTRO- CHROMIC MIRROR
GRN WIRE
GRY WIRE
HOT IN ON OR START
LEFT REAR COMBINATION LAMP (IN)
NCA WIRE
ORG/ WIRE
PCM (LEFT SIDE OF ENGINE COMPT)
PNK ON/START INPUT WIRE
PNK WIRE
POSITION SW
RED WIRE
RED/BLK WIRE
RIGHT REAR COMBINATION LAMP (IN)
SIG (1)
SIG (2)
SIG 3
SIG 4
TCU 2 FUSE
TRANSAXLE RANGE SWITCH (TOP OF TRANSAXLE ASSEMBLY)
W/ NAVIGATION
W/ UVO AUDIO
W/O NAVIGATION
Go to component -> Backup lamps circuit, hybrid -> PNK ON/START INPUT WIRE
