Kia Optima III (2010-2013) ips ips 5 control ctrl module Wiring diagrams
This page contains all the electrical diagrams for the component. ips ips 5 control ctrl module, in which he is found in the car Kia Optima III (2010-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram ips ips 5 control ctrl module (1 of 2)
A/C CONTROL MODULE
A/T
A/V, NAVIGATION HEAD UNIT
AMP
AMP FUSE
ARISU 2
ARISU 2 CTRL
AUDIO
AUTO A/C
AUTO HEAD LAMP LEVELING DEVICE MODULE
AUX, USB JACK
BLU WIRE
CIGAR LIGHTER INDICATOR
CRASH PAD SWITCH
DRIVER LEFT REAR IMS POWER SWITCH WINDOW SWITCH
FROM IPS 5 (DIAGRAM 4 OF 6)
FROM PDM 2 FUSE (DIAGRAM 3 OF 6)
FRONT ATM SEAT LEVER WARMER INDICATOR, CCS SWITCH
GLOVE BOX LAMP)
I/P JUNCTION BOX
I/P-A
I/P-D
I/P-G
INSTRUMENT CLUSTER
IPS 5
IPS 6
IPS CONTROL IPS 6 CONTROL MODULE
IPS IPS 5 CONTROL CTRL MODULE
LEFT FRONT FOG LAMP
MANUAL A/C
MULTIFUNCTION SWITCH
NCA WIRE
ORG/ WIRE
PASSENGER POWER OUTSIDE MIRROR
PASSENGER POWER WINDOW SWITCH
PNK WIRE
POWER WINDOW MAIN SWITCH
RED WIRE
RED/ORG WIRE
RHEOSTAT
RIGHT FRONT FOG LAMP
RIGHT HEAD- LAMP
RIGHT REAR COMBI- NATION LAMP (OUT)
RIGHT REAR POWER WINDOW SWITCH
TELLTALE LAMP
TO IPS 6 (DIAGRAM 4 OF 6)
W/ NAVI
W/ PASSENGER SAFETY POWER WINDOW W/O PASSENGER SAFETY POWER WINDOW
W/ REAR SEAT WARMER W/O REAR SEAT WARMER
W/O NAVI
W/O W/ HID HID
Go to component -> Power distribution circuit, except hybrid (4 of 6) -> IPS IPS 5 CONTROL CTRL MODULE
