Kia Optima III (2010-2013) immobilizer ind wiring diagram
This page shows the only wiring diagram for the component.immobilizer ind, which is found in the car Kia Optima III (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
immobilizer ind wiring diagram (1 of 1)
2.0L 2.4L
ANTENNA COIL
BLK WIRE
BLU WIRE
C P U
CHTG-AG
CHTG-BG
COMMS
E/R-B
FUSE
GRN WIRE
GRN/ORG WIRE
GRY WIRE
HOT AT ALL TIMES
I/P JUNCTION BOX
I/P-G
IGNITION KEY ILL, DOOR WARNING SWITCH
IMMO DL CHG-AG PCM (LEFT SIDE OF ENGINE COMPARTMENT)
IMMO IND CHG-BG
IMMOBILIZER IND
INSTRUMENT CLUSTER
INTERFACE
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
POWER CONNECTOR
REGULATOR
ROOM LP
TRANSPONER
VOLTAGE
Go to component -> Immobilizer circuit, except hybrid without smart key system -> IMMOBILIZER IND
