Kia Optima III (2010-2013) hot at all times bms c/f an fuse Wiring diagram
This page shows the only wiring diagram for the component.hot at all times bms c/f an fuse, which is found in the car Kia Optima III (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot at all times bms c/f an fuse (1 of 1)
B+ GND
BATTERY AMBIENT TEMPERATURE SENSOR
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/WHT WIRE
BLWR F/B
BMS ASSEMBLY
BMS BLOWER MOTOR
BMS BLOWER MOTOR RELAY
BMS CONTROL MODULE
BMS FUSE
BRN WIRE
C-CAN (H) C-CAN (L) RLY GND MAIN RLY GND FAN SPED
COMPUTER DATA LINES SYSTEM
E/R FUSE, RELAY BOX (LEFT SIDE OF ENGINE COMPT)
FAN SPD
GND GND 15 16 17 18 19 20 21 22 23 24 25 26
GRY WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES BMS C/F AN FUSE
I/P JUNCTION BOX (ABOVE LEFT KICK PANEL)
I/P-E
INVERTER
MAIN RLY
ORG/ WIRE
ORG/BLK WIRE
PNK WIRE
PNK/WHT WIRE
POWER RELAY ASSEMBLY
PRCHRG RLY
PWR IN
RED WIRE
RED/WHT WIRE
SIG
TEMP SNSR SIG
TO HYBRID BATTERY MODULE 1 (DIAGRAM 3 OF 6)
TO HYBRID BATTERY MODULE 9 (DIAGRAM 5 OF 6)
TO HYBRID BATTERY SAFETY PLUG (DIAGRAM 4 OF 6)
VIB GND GND
VOUT SIG
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
YEL/ORG WIRE
