Kia Optima III (2010-2013) front fog lamp on switch off Wiring diagrams
This page contains all the electrical diagrams for the component. front fog lamp on switch off, in which he is found in the car Kia Optima III (2010-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram front fog lamp on switch off (1 of 2)
2 15 14 HEAD LAMP HIGH SWITCH B-CAN LOW B-CAN HIGH
AUTO LIGHT SENSOR
AUTO LIGHT, PHOTO SENSOR (TOP CENTER OF DASH)
B-CAN TRANSCEIVER
BCM (LOWER CENTER OF DASH)
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DIMMER, PASSING SWITCH
FRONT FOG IND
FRONT FOG LAMP ON SWITCH OFF
GRN WIRE
HEAD
HEAD LAMP LOW SWITCH
HIGH BEAM IND
HIGH PASS
HOT AT ALL TIMES
I/P JUNCTION BOX
I/P-G
INSTRUMENT CLUSTER
LIGHT SWITCH
LOW PASS HIGH
MCU
MULTI- FUNCTION SWITCH
ORG/BLK WIRE
PNK TAIL LAMP SWITCH WIRE
PNK WIRE
POWER CONNECTOR
ROOM LP FUSE
TAIL HEAD OFF AUTO
TAIL OFF AUTO
WHT WIRE
WHT/ORG WIRE
YEL/ORG WIRE
Go to component -> Autolamps circuit (2 of 2) -> FRONT FOG LAMP ON SWITCH OFF
Wiring diagram front fog lamp on switch off (2 of 2)
15 14 B-CAN LOW B-CAN HIGH
3 1 FRONT FOG LAMP SWITCH HEAD LAMP SWITCH
B-CAN TRANSCEIVER
BCM (LOWER CENTER OF DASH)
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DIMMER, PASSING SWITCH
FRONT FOG IND
FRONT FOG LAMP ON SWITCH OFF
HEAD
HEAD LAMP HIGH SWITCH
HEAD LAMP LOW SWITCH
HEAD TAIL OFF AUTO
HIGH BEAM IND
HIGH PASS
HOT AT ALL TIMES
I/P JUNCTION BOX
I/P-G
INSTRUMENT CLUSTER
LIGHT SWITCH
LOW PASS HIGH
MCU
MULTI- FUNCTION SWITCH
ORG/BLK WIRE
PNK TAIL LAMP SWITCH WIRE
PNK WIRE
POWER CONNECTOR
ROOM LP FUSE
TAIL OFF AUTO
WHT WIRE
WHT/ORG WIRE
YEL/ORG WIRE
Go to component -> Headlamps circuit (2 of 2) -> FRONT FOG LAMP ON SWITCH OFF
