Kia Optima III (2010-2013) ems ip b+3 abs 2 fuse fuse fuse Wiring diagram
This page shows the only wiring diagram for the component.ems ip b+3 abs 2 fuse fuse fuse, which is found in the car Kia Optima III (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ems ip b+3 abs 2 fuse fuse fuse (1 of 1)
2.0L
2.0L 2.4L
2.4L
2.4L 2.0L
A/T
A/T M/T
ABS 1 FUSE
ALTERNATOR
AMS RR HTD FUSE FUSE
B/HORN RELAY
BATTERY
BATTERY SENSOR
BATTERY, BATTERY FUSE BOX ALT FUSE
BLK WIRE
BLOWER RELAY
BLU/ORG WIRE
C/FAN FUSE
C/FAN HI FUSE
C/FAN HI RELAY
C/FAN LO RELAY
CHG-AG
CHG-BG
CHTG-AG
CHTG-BG
DEICER FUSE
DEICER RELAY
E/R-A
E/R-B
E/R-EMS
ECU 1 HORN FUSE FUSE
ECU 3 FUSE
ECU 4 FUSE
EMS BOX ENGINE ROOM RELAY BOX
EMS IP B+3 ABS 2 FUSE FUSE FUSE
ENGINE CONTROL HORN RELAY
ENGINE ROOM RELAY BOX
ENGINE ROOM RELAY BOX (LEFT SIDE OF ENGINE COMPT)
EPS CONTROL TO FUSE, MODULE RELAY BOX (DIAGRAM 6 OF 6)
ESC MODULE
F/PUMP FUSE
F/PUMP RELAY
FROM EMS C/FAN FUSE (HI) (DIAGRAM RELAY 1 OF 6)
FROM MDPS FUSE (DIAGRAM 1 OF 6)
GRN (OR PNK) WIRE
GRN WIRE
HAC ABS 3 RELAY FUSE
HAC RELAY
IGN 1 FUSE
IGN 2 FUSE
IP B+1 BLOWER FUSE FUSE
IP B+2 FUSE
LIN LINE
M/T
MDPS FUSE
MOTOR
MULTI FUSE
MULTIPURPOSE CHECK CONNECTOR
ORG/ WIRE
PCM
PCM (LEFT SIDE OF ENGINE COMPT)
PNK WIRE
PNK/BLK WIRE
RED WIRE
RELAY
RR HTD FUSE
RR HTD RELAY
SNSR
STOP ESC MODULE LAMP SWITCH
STOP LP FUSE
TCU 1 FUSE
TCU 2 FUSE
TO IG 1 FUSE (DIAGRAM 2 OF 6)
TO IGNITION SWITCH (DIAGRAM 2 OF 6)
TO P/SEAT DRV FUSE (DIAGRAM 3 OF 6)
TO PDM 1 FUSE (DIAGRAM 5 OF 6)
TO STOP LP FUSE (DIAGRAM 1 OF 6)
TO TO SUNROOF EMS BOX FUSE (DIAGRAM (DIAGRAM 1 OF 6) 5 OF 6)
TRANSAXLE VEHICLE BACK-UP RANGE SPEED LAMP SWITCH SENSOR SWITCH
W/ SMART KEY
W/O SMART KEY
WHT WIRE
YEL/ORG WIRE
Go to component -> Power distribution circuit, except hybrid (1 of 6) -> EMS IP B+3 ABS 2 FUSE FUSE FUSE
