Kia Optima III (2010-2013) driver window switch Wiring diagrams

This page contains all the electrical diagrams for the component. driver window switch, in which he is found in the car Kia Optima III (2010-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

driver window switch wiring diagram (1 of 3)

AUTO DOWN AUTO UP BLK (OR BRN) WIRE BLK WIRE BLU WIRE BOX) BRN (OR BLU) WIRE BRN WIRE DOOR LOCK SWITCH DOOR LOCKS SYSTEM DOWN DOWN OFF DOWN OFF UP DRIVER WINDOW SWITCH GRN WIRE GRY WIRE HOT AT ALL TIMES I/P JUNCTION I/P-A ILL IPS CONTROL MODULE POWER WINDOW RELAY CONTROL LEFT REAR POWER WINDOW MOTOR (IN LEFT REAR DOOR) LEFT REAR WINDOW SWITCH LH RELAY OFF UP ORG/ WIRE P/WDW LH FUSE P/WDW RH FUSE PASSENGER WINDOW SWITCH PNK WIRE PNK/BLK WIRE POWER WINDOW POWER WINDOW MAIN SWITCH POWER WINDOW RH RED WIRE RELAY RIGHT REAR POWER WINDOW MOTOR RIGHT REAR POWER WINDOW SWITCH RIGHT REAR WINDOW SWITCH UP 4 1 W/ HYBRID W/ REAR SEAT WARMER W/O REAR SEAT WARMER W/O HYBRID WHT WIRE WINDOW LOCK SWITCH YEL WIRE YEL/BLK WIRE

Go to component -> Power windows circuit, with driver and passenger safety power windows (1 of 2) -> DRIVER WINDOW SWITCH

driver window switch wiring diagram (2 of 3)

AUTO DOWN AUTO UP BLK WIRE BLU WIRE BOX) BRN WIRE DOOR LOCK SWITCH DOOR LOCKS SYSTEM DOWN DOWN OFF DRIVER WINDOW SWITCH GRN WIRE GRY WIRE HOT AT ALL TIMES I/P JUNCTION I/P-A ILL IPS CONTROL MODULE POWER WINDOW RELAY CONTROL LEFT REAR POWER WINDOW MOTOR (IN LEFT REAR DOOR) LEFT REAR WINDOW SWITCH LH RELAY OFF DOWN OFF UP ORG/ WIRE P/WDW LH FUSE P/WDW RH FUSE PASSENGER POWER WINDOW MOTOR (FRONT OF RIGHT FRONT DOOR) PASSENGER WINDOW SWITCH PNK WIRE PNK/BLK WIRE POWER WINDOW POWER WINDOW MAIN SWITCH POWER WINDOW RH RED WIRE RELAY RIGHT REAR POWER WINDOW MOTOR RIGHT REAR WINDOW SWITCH UP OFF W/ HYBRID W/ HYBRID W/O HYBRID W/O HYBRID WHT WIRE WINDOW LOCK SWITCH YEL WIRE YEL/BLK WIRE

Go to component -> Power windows circuit, with driver safety power windows (1 of 2) -> DRIVER WINDOW SWITCH

driver window switch wiring diagram (3 of 3)

AUTO DOWN BLK WIRE BLK/ORG WIRE BLU WIRE BOX) BRN WIRE CONTROL UNIT) DOOR LOCK SWITCH DOOR LOCKS SYSTEM DOWN DOWN OFF DRIVER WINDOW SWITCH GRN WIRE GRY WIRE HOT AT ALL TIMES I/P JUNCTION I/P-A ILLU IPS CONTROL MODULE POWER WINDOW RELAY CONTROL LEFT REAR POWER WINDOW MOTOR (IN LEFT REAR DOOR) LEFT REAR WINDOW SWITCH LH RELAY OFF UP ORG/ WIRE P/WDW LH FUSE P/WDW RH FUSE PASSENGER POWER WINDOW MOTOR (FRONT OF RIGHT FRONT DOOR) PASSENGER WINDOW SWITCH PNK WIRE PNK/BLK WIRE POWER WINDOW POWER WINDOW MAIN SWITCH POWER WINDOW RH RED WIRE RELAY RIGHT REAR POWER WINDOW MOTOR RIGHT REAR WINDOW SWITCH UP OFF WHT WIRE WINDOW LOCK SWITCH YEL WIRE YEL/BLK WIRE

Go to component -> Power windows circuit, without driver safety power windows (1 of 2) -> DRIVER WINDOW SWITCH

Kia Optima III (2010-2013) driver window switch Wiring diagrams

driver window switch wiring diagram (1 of 3)

List of components:

driver window switch wiring diagram (2 of 3)

List of components:

driver window switch wiring diagram (3 of 3)

List of components:
