Kia Optima III (2010-2013) driver front height adju- ster switch Wiring diagram
This page shows the only wiring diagram for the component.driver front height adju- ster switch, which is found in the car Kia Optima III (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver front height adju- ster switch (1 of 1)
10-WAY
2 WAY
BLK WIRE
BLU WIRE
BOX)
BRN WIRE
BWD
DRIVER FRONT
DRIVER FRONT HEIGHT ADJU- STER SWITCH
DRIVER LUMBAR
DRIVER LUMBAR SUPPORT MOTOR
DRIVER LUMBAR SUPPORT SWITCH
DRIVER REAR
DRIVER REAR HEIGHT ADJUSTER SWITCH
DRIVER RECLINING
DRIVER RECLINING LIMIT SWITCH
DRIVER RECLINING SWITCH
DRIVER SEAT MANUAL SWITCH
DRIVER SLIDE MOTOR (BELOW
DRIVER SLIDE SWITCH
DRIVER'S SEAT
GRN WIRE
GRY WIRE
HEIGHT ADJUSTER MOTOR
HOT AT ALL TIMES
I/P JUNCTION
I/P-A
J/C
MOTOR
P/SEAT (DRV) FUSE
RED WIRE
SUPPORT MOTOR
WHT WIRE
YEL WIRE
Go to component -> Driver power seat circuit -> DRIVER FRONT HEIGHT ADJU- STER SWITCH
