Kia Optima III (2010-2013) driver driver ccs seat cushion warmer warmer module Wiring diagrams
This page contains all the electrical diagrams for the component. driver driver ccs seat cushion warmer warmer module, in which he is found in the car Kia Optima III (2010-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram driver driver ccs seat cushion warmer warmer module (1 of 2)
A/V, AUDIO NAVIGATION HEAD UNIT
ARISU 1
BLU/ORG WIRE
BRN/BLK WIRE
DOOR LOCK RELAY
DOOR UNLOCK RELAY
DR LOCK FUSE
DRIVER DRIVER CCS SEAT CUSHION WARMER WARMER MODULE
DRIVER POWER OUTSIDE MIRROR
DRIVER POWER WINDOW SAFETY MODULE
EQUIPPED)
FROM IP B+1 FUSE (DIAGRAM 1 OF 6)
FROM IP B+3 FUSE (DIAGRAM 1 OF 6)
GRN WIRE
GRN/BLK WIRE
I/P JUNCTION BOX
I/P-A
I/P-C
I/P-D
I/P-E
I/P-G
IPS 3
IPS CONTROL MODULE IPS 3 CTRL
KEY SOLENOID
LEFT HEAD- LAMP
LEFT LICENSE LAMP
LEFT POWER TRUNK LID WINDOW RELAY RELAY
LEFT REAR COMBI- NATION LAMP (OUT)
LEFT REAR COMBINATION LAMP (OUT)
LEFT REAR SEAT WARMER (W/O RELAY SMART KEY)
LEFT RIGHT REAR LICENSE COMBI- LAMP NATION LAMP (IN)
LT GRN WIRE
NCA WIRE
ORG/ WIRE
P/WDW RH FUSE
P/WDW TRUNK LH FUSE FUSE
PANORAMA SUNROOF
PASSENGER PASS- CCS ENGER CUSHION SEAT WARMER WARMER MODULE
PASSENGER POWER WINDOW SAFETY MODULE
PDM 1 FUSE
PNK I/P-C WIRE
PNK WIRE
POWER AUDIO CONNECTOR FUSE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/YEL WIRE
RIGHT HEAD- LAMP
RIGHT POWER WINDOW RELAY
RIGHT REAR COMBI- NATION LAMP (IN)
RIGHT REAR COMBI- NATION LAMP (OUT)
RIGHT REAR SEAT WARMER RELAY
S/HEATER FRT FUSE
S/HEATER MODULE 3 RR FUSE FUSE
SMART KEY CONTROL MODULE (IF
SPORT MODE SWITCH (A/T)
SUNROOF FUSE
TO ROOM LP FUSE (DIAGRAM 6 OF 6)
TRUNK FUEL ROOM FILLER LAMP DOOR, TRUNK LID SWITCH
TURN SIGNAL LAMP SOUND RELAY
TWO TURN UNLOCK RELAY
W/ W/O CCS CCS
W/ W/O NAVI NAVI
YEL WIRE
YEL/BLK WIRE
Go to component -> Power distribution circuit, except hybrid (5 of 6) -> DRIVER DRIVER CCS SEAT CUSHION WARMER WARMER MODULE
Wiring diagram driver driver ccs seat cushion warmer warmer module (2 of 2)
