Kia Optima III (2010-2013) computer data lines system exterior lights system Wiring diagrams
This page contains all the electrical diagrams for the component. computer data lines system exterior lights system, in which he is found in the car Kia Optima III (2010-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram computer data lines system exterior lights system (1 of 2)
15 16 P POSITION IMMO CLOCK
2.0L
2.4L
B-CAN TRANSCEIVER
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/ORG WIRE
BOX)
BRN WIRE
BRN/ORG WIRE
C-CAN LOW C-CAN HIGH 2 3
C-CAN TRANSCEIVER
CHG-AG
CHTG-AG
COMPUTER DATA LINES SYSTEM
COMPUTER DATA LINES SYSTEM EXTERIOR LIGHTS SYSTEM
DATA
E/R FUSE, RELAY BOX (LEFT SIDE OF ENGINE COMPT)
GRN WIRE
GRN/BLK WIRE
GROUND
GROUND GROUND ANT GND ANT GND
GRY WIRE
GRY/ORG WIRE
HIGH LOW
HOLDER ILL
HOT AT ALL TIMES
I/P JUNCTION
I/P-A
I/P-G
IMMO
IMMO IND SSB AMBER SSB ILL POWER GROUND GROUND 2 3
INSTRUMENT CLUSTER
K-LINE STOP LAMP SIGNAL IMMO DATA RF SIGNAL EMS COM 7 8
LOW HIGH
MCU
ORG/ WIRE
ORG/BLK WIRE
P POSITION SWITCH
PCM (LEFT SIDE OF ENGINE COMPT)
POWER CONNECTOR
POWER POWER ANT PWR ANT PWR
RED WIRE
RED/ORG WIRE
RF RECEIVER
ROOM LP FUSE
SMART KEY ANTENNA 1 (LOWER LEFT CENTER OF DASH)
SMART KEY BUMPER ANTENNA (REAR BUMPER)
SMART KEY CONTROL MODULE (UNDER RIGHT SIDE OF DASH)
SPORT MODE SWITCH
SSB GREEN ILL GND POWER POWER
STOP LAMP POWER
STOP LP FUSE
WHT WIRE
WHT/ORG WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Immobilizer circuit, except hybrid with smart key system (3 of 3) -> COMPUTER DATA LINES SYSTEM EXTERIOR LIGHTS SYSTEM
Wiring diagram computer data lines system exterior lights system (2 of 2)
15 16 P POSITION IMMO CLOCK
B-CAN TRANSCEIVER
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/ORG WIRE
BOX)
BRN WIRE
C-CAN LOW C-CAN HIGH 2 3
C-CAN TRANSCEIVER
CHG-K
COMPUTER DATA LINES SYSTEM
COMPUTER DATA LINES SYSTEM EXTERIOR LIGHTS SYSTEM
DATA
E/R FUSE, RELAY BOX
GRN WIRE
GRN/BLK WIRE
GROUND
GROUND GROUND ANT GND ANT GND
GRY/ORG WIRE
HIGH LOW
HOLDER ILL
HOT AT ALL TIMES
I/P JUNCTION
I/P-A
I/P-G
IMMO
IMMO IND SSB AMBER SSB ILL POWER GROUND GROUND 2 3
INSTRUMENT CLUSTER
K-LINE STOP LAMP SIGNAL IMMO DATA RF SIGNAL EMS COM 7 8
LOW HIGH
MCU
ORG/ WIRE
P POSITION SWITCH
PCM (LEFT SIDE OF ENGINE COMPT)
POWER CONNECTOR
POWER DISTRIBUTION SYSTEM
POWER POWER ANT PWR ANT PWR
RED WIRE
RED/ORG WIRE
RF RECEIVER
ROOM LP FUSE
SMART KEY ANTENNA 1 (LOWER LEFT CENTER OF DASH)
SMART KEY BUMPER ANTENNA (REAR BUMPER)
SMART KEY CONTROL MODULE (UNDER RIGHT SIDE OF DASH)
SPORT MODE SWITCH
SSB GREEN ILL GND POWER POWER
STOP LAMP POWER
STOP LP FUSE
WHT WIRE
WHT/ORG WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Immobilizer circuit, hybrid (3 of 3) -> COMPUTER DATA LINES SYSTEM EXTERIOR LIGHTS SYSTEM
