Kia Optima III (2010-2013) ams fuse (left side of engine Wiring diagrams
This page contains all the electrical diagrams for the component. ams fuse (left side of engine, in which he is found in the car Kia Optima III (2010-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram ams fuse (left side of engine (1 of 2)
AMS FUSE (LEFT SIDE OF ENGINE
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BRK LT SW
BRK TEST SW
BRN WIRE
C/FAN RLY CTRL HI IMMO IND
CHTGINJ
CMP 1 SIG CMP 2 SIG
COMPT)
COOLING FANS SYSTEM
COOLING FANS SYSTEM INSTRUMENT CLUSTER SYSTEM
E/R-A
E/R-B
ECU 1 FUSE
ECU 4 FUSE
EMS BOX
ENG CTRL RLY CTRL
ENGINE CONTROL RELAY
ENGINE ROOM
F/PUMP FUSE
FUEL PUMP MOTOR
FUEL PUMP RELAY
FUEL SENDER
FUEL SENDER, FUEL PUMP MOTOR
FUSE (DIAGRAM 3 OF 6)
GRN WIRE
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
HOT IN ON OR START
INJ CTRL 2 HI INJ CTRL 2 LO WHEEL SPD (-) CKP GND
INJ CTRL 3 HI INJ CTRL 3 LO ON/START IN
INJECTOR FUSE
INJECTORS (LEFT SIDE OF ENGINE)
INSTRUMENT CLUSTER SYSTEM
KNOCK SENSOR (LEFT SIDE OF ENGINE)
LIN DIAG DATA LINE C/FAN RLY CTRL LO
NCA WIRE
ORG/ GRN WIRE
ORG/ WIRE
OXYGEN SENSOR (UP) (EXHAUST MANIFOLD)
PCM (LEFT SIDE OF ENGINE COMPT)
PNK WIRE
PNK/BLK WIRE
RED WIRE
RELAY BOX
SHIELD SNSR GND CMP 1 GND CMP 2 GND
SNSR 1 FUSE
SNSR 3 FUSE
TO IGN COIL FUSE (DIAGRAM 3 OF 6)
TO SNSR 2
W/ SULEV
W/ ULEV
WHT WIRE
WHT/BLK WIRE
WIPER "P" IN ALT (FR) ALT (COM)
WIPER/WASHER SYSTEM STARTING/CHARING SYSTEM
YEL WIRE
YEL/ORG WIRE
Go to component -> Wiring diagram engine performance 2.0l (1 of 6) -> AMS FUSE (LEFT SIDE OF ENGINE
