Kia Optima III (2010-2013) 15 14 b-can low b-can high Wiring diagram
This page shows the only wiring diagram for the component.15 14 b-can low b-can high, which is found in the car Kia Optima III (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 15 14 b-can low b-can high (1 of 1)
15 14 B-CAN LOW B-CAN HIGH
3 1 FRONT FOG LAMP SWITCH HEAD LAMP SWITCH
B-CAN TRANSCEIVER
BCM (LOWER CENTER OF DASH)
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DIMMER, PASSING SWITCH
FRONT FOG IND
FRONT FOG LAMP ON SWITCH OFF
HEAD
HEAD LAMP HIGH SWITCH
HEAD LAMP LOW SWITCH
HEAD TAIL OFF AUTO
HIGH BEAM IND
HIGH PASS
HOT AT ALL TIMES
I/P JUNCTION BOX
I/P-G
INSTRUMENT CLUSTER
LIGHT SWITCH
LOW PASS HIGH
MCU
MULTI- FUNCTION SWITCH
ORG/BLK WIRE
PNK TAIL LAMP SWITCH WIRE
PNK WIRE
POWER CONNECTOR
ROOM LP FUSE
TAIL OFF AUTO
WHT WIRE
WHT/ORG WIRE
YEL/ORG WIRE
Go to component -> Headlamps circuit (2 of 2) -> 15 14 B-CAN LOW B-CAN HIGH
