Shift interlock circuit for Kia Optima II facelift (2008-2010)
Shift interlock circuit
12 13 3 14 15 ON INPUT ACC/ON STOP SIG P INPUT N INPUT
15 7 GND PARKING SW
6 17 KEY SOL ATM SOL
ADJ PEDAL FUSE
BCM (BODY CONTROL MODULE) (UNDER LEFT SIDE OF DASH)
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
D/CLOCK FUSE
E/R JUNCTION BOX (LEFT SIDE OF ENGINE COMPT)
GRN WIRE
GRN/ORG WIRE
GRY WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
HOT IN ON I/P MODULE 2 FUSE JUNCTION BOX (ABOVE LEFT KICK PANEL)
HOT IN ON OR START E/R JUNCTION BACKUP FUSE BOX (LEFT SIDE OF ENGINE COMPT)
I/P-B
I/P-D
KEY INTERLOCK ATM SWITCH SOLENOID (PARKING SWITCH)
KEY SOLENOID (BASE OF STEERING COLUMN)
ORG/ WIRE
PNK WIRE
RED WIRE
RED/BLK WIRE
SEATS SYSTEM
SPORT MODE SWITCH
STOP LAMP SWITCH (ABOVE BRAKE PEDAL, ON BRACKET)
TRANSAXLE RANGE SWITCH (TOP OF TRANSAXLE ASSEMBLY)
TRANSMISSIONS SYSTEM
WHT WIRE
WHT/BLK WIRE
