Kia Optima II facelift (2008-2010) windshield defogger switch pnk Wiring diagram
This page shows the only wiring diagram for the component.windshield defogger switch pnk, which is found in the car Kia Optima II facelift (2008-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram windshield defogger switch pnk (1 of 1)
BCM (UNDER LEFT
BLK WIRE
BLU WIRE
ENGINE RUNNING IP SIG
GRN WIRE
GRN/BLK WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
I/P JUNCTION BOX (ABOVE LEFT KICK PANEL)
I/P-B
ICM RELAY BOX (UNDER LEFT SIDE OF DASH)
ILL
IND
NCA WIRE
ORG/ WIRE
PNK WIRE
RED WIRE
SIDE OF DASH)
STARTING/ CHARGING SYSTEM
W/ DEICER FUSE
WINDSHIELD DEFOGGER
WINDSHIELD DEFOGGER RELAY
WINDSHIELD DEFOGGER RELAY CTRL
WINDSHIELD DEFOGGER SWITCH
WINDSHIELD DEFOGGER SWITCH PNK WIRE
YEL WIRE
Go to component -> Defoggers circuit, without heated mirrors -> WINDSHIELD DEFOGGER SWITCH PNK WIRE
