Kia Optima II facelift (2008-2010) t/turn unlock relay Wiring diagrams
This page contains all the electrical diagrams for the component. t/turn unlock relay, in which he is found in the car Kia Optima II facelift (2008-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
t/turn unlock relay wiring diagram (1 of 2)
B/ALARM RLY CTRL
BCM (UNDER LEFT SIDE OF DASH)
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
BRN/ORG WIRE
BURGLAR HORN RELAY
DRIVER'S DOOR UNLOCK SWITCH (IN LEFT FRONT DOOR) UL
E/R JUNCTION BOX (LEFT SIDE OF ENGINE COMPT)
GRN WIRE
GRY WIRE
HOOD SW
HOOD SWITCH (AT RIGHT FRONT CORNER OF ENGINE COMPT)
HORN FUSE
HOT AT ALL TIMES
ICM RELAY BOX (UNDER LEFT SIDE
JOINT CONNECTOR
LEFT "C" PILLAR)
LEFT REAR COMBINATION LAMP
LEFT REAR DOOR LOCK ACTUATOR
LOCK
NCA WIRE
OF DASH)
ON INPUT
ON/START
ORG/ WIRE
ORG/BLK WIRE
PASSENGER'S DOOR UL UNLOCK SWITCH (IN RIGHT FRONT DOOR)
PNK WIRE
PNK/BLK WIRE
RED WIRE
RED/BLK WIRE
RLY CTRL
SIG
STARTING/ CHARGING SYSTEM
T/TURN UNLOCK RELAY
TRUNK UNLOCK SWITCH (AT REAR OF TRUNK)
UN LK SW
UN LOCK
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Forced entry circuit (1 of 2) -> T/TURN UNLOCK RELAY
