Kia Optima II facelift (2008-2010) tail lamp relay control output Wiring diagram
This page shows the only wiring diagram for the component.tail lamp relay control output, which is found in the car Kia Optima II facelift (2008-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tail lamp relay control output (1 of 1)
1 2 SEAT BELT SW GND
8 7 3 2 SEAT BELT SW BUCKLE SW GND GND
ADVANCED AIR BAG
BCM (UNDER LEFT SIDE OF DASH)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN/ORG WIRE
CHIME BUZZER
CLUSTER FUSE
DEPOWERED AIR BAG
DOOR AJAR INDICATOR
DOOR SWITCH
DRIVER SEAT BUCKLE SWITCH
GRN WIRE
HEAD
HOT AT ALL TIMES
HOT IN ON OR START
I/P JUNCTION BOX (ABOVE LEFT
I/P-A
I/P-B
I/P-E
I/P-L
INSTRUMENT CLUSTER
JOINT CONNECTOR
KEY ILLUMINATION SWITCH
KICK PANEL)
LEFT FRONT DOOR SWITCH (ON LEFT "B" PILLAR)
LEFT REAR DOOR SWITCH (ON LEFT "C" PILLAR)
LH BUCKLE SW
LIGHT SWITCH
MEMORY FUSE
MULTI- FUNCTION SWITCH
NCA WIRE
ON/START INPUT
ORG/ WIRE
ORG/BLK WIRE
PARK OFF
POWER CONNECTOR
RED WIRE
RED/ORG WIRE
SEAT BELT IND
SEAT BELT INDICATOR
SEAT BELT SW-
SEAT BELT/OVER SPEED/KEY OPERATING WARNING
SRS CONTROL MODULE (FRONT OF CENTER CONSOLE)
SWITCH INPUT
TAIL LAMP RELAY CONTROL OUTPUT
YEL WIRE
YEL/BLK WIRE
YEL/ORG WIRE
Go to component -> Chime circuit -> TAIL LAMP RELAY CONTROL OUTPUT
