Kia Optima II facelift (2008-2010) tail lamp relay auto cut control output Wiring diagram
This page shows the only wiring diagram for the component.tail lamp relay auto cut control output, which is found in the car Kia Optima II facelift (2008-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tail lamp relay auto cut control output (1 of 1)
2.4L
7 3 HAZARD RELAY CONTROL
A/T
ABS CONTROL MODULE (LEFT REAR OF ENGINE COMPT)
ADJUSTABLE PEDAL
BACK-UP FUSE
BCM (UNDER LEFT SIDE OF DASH)
BLK WIRE
BLU/ORG WIRE
BRN WIRE
ENGINE COMPT)
ENGINE ROOM JUNCTION BOX (LEFT SIDE OF ENGINE COMPT)
ESC CONTROL MODULE (LEFT REAR OF
FRONT TURN SIGNAL LAMP
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRY WIRE
GRY/BLK WIRE
HIGH MOUNTED STOP LAMP
HOT AT ALL TIMES
HOT IN ON OR START
I/P-D
INSTRUMENT CLUSTER
INSTRUMENT PANEL JUNCTION BOX (ABOVE LEFT KICK PANEL)
LEFT "C" PILLAR)
LEFT HEAD- LAMP FRONT TURN SIGNAL LAMP
LEFT REAR COMBI- NATION LAMP (OUT)
LEFT TURN IND
M/T, W/O
NCA WIRE
PARKING LAMP
PCM (LEFT REAR OF ENGINE COMPT)
PNK WIRE
RED WIRE
RIGHT HEADLAMP
RIGHT REAR COMBINATION LAMP (OUT)
RIGHT TURN IND
STOP LAMP
STOP LAMP SWITCH (ABOVE BRAKE PEDAL, ON BRACKET)
STOP LP FUSE
TAIL LAMP IND
TAIL LAMP RELAY AUTO CUT CONTROL INPUT
TAIL LAMP RELAY AUTO CUT CONTROL OUTPUT
TURN TAIL SIGNAL LAMP LAMP
W/ ABS
W/ ANALOG TYPE
W/ DRL
W/ ESC
W/ SUPERVISION TYPE
WHT WIRE
WHT/BLK WIRE
WHT/ORG WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> TAIL LAMP RELAY AUTO CUT CONTROL OUTPUT
