Kia Optima II facelift (2008-2010) rear defogger switch ip/n Wiring diagram
This page shows the only wiring diagram for the component.rear defogger switch ip/n, which is found in the car Kia Optima II facelift (2008-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear defogger switch ip/n (1 of 1)
A/C CONTROL MODULE DEFOGGER SWITCH
AUTOMATIC A/C MANUAL A/C
BCM (UNDER LEFT SIDE OF DASH)
BLK WIRE
BRN WIRE
DEFOGGER
DRIVER OUTSIDE MIRROR MOTOR, DEFOGGER (TOP OF LEFT FRONT DOOR)
ENGINE ROOM JUNCTION BOX (LEFT SIDE OF ENGINE COMPT)
ENGINE RUNNING IP SIG
GLASS ANTENNA MODULE
GRN WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
I/P-A
I/P-G
I/P-J
IND
INSTRUMENT PANEL JUNCTION BOX (ABOVE LEFT KICK PANEL)
JOINT CONNECTOR
LEFT "C" PILLAR)
MANUAL A/C AUTOMATIC A/C
MIRR HTD FUSE
NCA WIRE
ORG/ WIRE
PASSENGER OUTSIDE MIRROR MOTOR, DEFOGGER (TOP FRONT OF RIGHT FRONT DOOR)
REAR DEFOGGER RELAY
REAR DEFOGGER RELAY CTRL
REAR DEFOGGER SWITCH IP/N
REAR WINDOW DEFOGGER
RED WIRE
RR HTD FUSIBLE LINK
STARTING/ CHARGING SYSTEM
YEL WIRE
Go to component -> Defoggers circuit, with heated mirrors -> REAR DEFOGGER SWITCH IP/N
