Kia Optima II facelift (2008-2010) multi-function switch instrument cluster Wiring diagram

A/C CONTROL MODULE A/T ADJUSTABLE PEDAL SWITCH AUDIO AUTOMATIC A/C BCM (UNDER LEFT SIDE OF DASH) BLK WIRE BLU WIRE BLU/ORG WIRE CIGARETTE LIGHTER ILL ASHTRAY ILL DIGITAL CLOCK DRIVER POWER WINDOW SWITCH DRIVER SEAT WARMER SWITCH ENGINE ROOM JUNCTION BOX (LEFT SIDE OF ENGINE COMPT) ESC SWITCH GLOVE BOX LAMP) GLOVE BOX SWITCH (LEFT SIDE OF GLOVE BOX) GRY WIRE HAZARD SWITCH HEAD HOT AT ALL TIMES HOT IN ON I/P-A I/P-B INSTRUMENT PANEL JUNCTION BOX (ABOVE LEFT KICK PANEL) LEFT REAR POWER WINDOW SWITCH LIGHT SWITCH MANUAL A/C MODULE 2 FUSE MULTI- MEDIA JACK MULTI-FUNCTION SWITCH INSTRUMENT CLUSTER NCA WIRE PARK OFF PASSENGER POWER WINDOW SWITCH PASSENGER SEAT WARMER SWITCH PNK I/P-K WIRE PNK WIRE RED WIRE RHEO GROUND RHEOSTAT RIGHT REAR POWER WINDOW SWITCH RLY INPUT RLY OUTPUT SPORT MODE SWITCH SVC TAIL ILL(+) TAIL FUSE TAIL LAMP RELAY TAIL RH FUSE W/ CTR DOOR LOCK W/O CTR DOOR LOCK WIND- SHIELD DEFOGGER SWITCH YEL WIRE YEL/BLK WIRE
