Kia Optima II facelift (2008-2010) hot at all times frt fog fuse Wiring diagram
This page shows the only wiring diagram for the component.hot at all times frt fog fuse, which is found in the car Kia Optima II facelift (2008-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot at all times frt fog fuse (1 of 1)
AUTO SWITCH
BCM (UNDER LEFT SIDE OF DASH)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BOX (ABOVE LEFT KICK PANEL)
DIMMER, PASSING SWITCH
ENGINE ROOM JUNCTION BOX (LEFT SIDE OF ENGINE COMPT)
FRONT FOG LAMP
FRONT FOG LAMP RELAY
GRN WIRE
GRN/BLK WIRE
GROUND
GRY WIRE
GRY/ORG WIRE
H/LP (LOW) FUSE
H/LP HI FUSE
HEAD LAMP RELAY(LOW)
HEAD- LAMP RELAY (HIGH)
HEAD- LAMP RELAY (LOW)
HEAD- LAMP SWITCH
HIGH FLASH SWITCH ON
HOT AT ALL TIMES
HOT AT ALL TIMES FRT FOG FUSE
HOT IN ON
I/P-B
I/P-E
I/P-J
INSTRUMENT PANEL JUNCTION
JOINT
LEFT FRONT FOG LAMP RIGHT FRONT FOG LAMP
LEFT HEADLAMP
LIGHT SWITCH
LO HI
LOW FLASH
LOW HIGH HIGH FLASH
MODULE 2 FUSE
MULTI- FUNCTION SWITCH
NCA WIRE
OFF
OFF LOW
ON/START INPUT
ORG/ WIRE
PARK HEAD
PARK OFF HEAD
PNK PNK WIRE
PNK WIRE
PNK/BLK WIRE
RED WIRE
RIGHT HEADLAMP
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Headlamps circuit, with drl (1 of 2) -> HOT AT ALL TIMES FRT FOG FUSE
