Kia Optima II facelift (2008-2010) driver slide limit switch Wiring diagram
This page shows the only wiring diagram for the component.driver slide limit switch, which is found in the car Kia Optima II facelift (2008-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver slide limit switch (1 of 1)
BLK WIRE
DRIVER CUSHION WARMER
DRIVER DOOR LOCK ACTUATOR
DRIVER DOOR UNLOCK SWITCH
DRIVER OUTSIDE MIRROR MOTOR
DRIVER POWER WINDOW SWITCH
DRIVER RECLINING LIMIT SWITCH
DRIVER SEAT MANUAL SWITCH
DRIVER SLIDE LIMIT SWITCH
FUEL FILLER DOOR, TRUNK LID SWITCH
HIGH MOUNTED STOP LAMP
HOME LINK
J/C
LEFT "C" PILLAR)
LEFT LICENSE LAMP
LEFT REAR COMBINATION LAMP (IN)
LEFT REAR COMBINATION RIGHT LAMP LICENSE (OUT) LAMP
LEFT REAR DOOR LOCK ACTUATOR
LEFT REAR POWER FUEL WINDOW FILLER SWITCH ACTUATOR
LEFT VANITY LAMP
NCA WIRE
OVERHEAD CONSOLE ASSEMBLY
POWER OUTSIDE MIRROR SWITCH
RAIN SENSOR
RIGHT REAR COMBINATION LAMP (IN)
RIGHT VANITY LAMP
ROOM LAMP
SAFETY WINDOW MOTOR
SUNROOF CONTROL MODULE
TRUNK LID LATCH
TRUNK UNLOCK SWITCH
Go to component -> Ground distribution circuit (3 of 3) -> DRIVER SLIDE LIMIT SWITCH
