Supplemental restraints circuit, early production for Kia Optima II (2005-2008)
Supplemental restraints circuit, early production
A/BAG FUSE
A/BAG IND FUSE
AIR BAG CONTROL UNIT (AT LOWER CENTER OF DASH, ON FLOOR TUNNEL)
AIR BAG INDICATOR
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
CLOCK- SPRING
DATA LINK CONNECTOR (DLC) (PARTIAL) (UNDER LEFT SIDE OF DASH)
DRIVER AIRBAG
DRIVER BUCKLE SWITCH (IN DRIVER'S SEAT BELT BUCKLE)
DRIVER SATELLITE SENSOR (NEAR BASE OF LEFT "B" PILLAR)
DRIVER SIDE AIRBAG (IN DRIVER'S SEAT)
GRN WIRE
GRN/ORG WIRE
HOT IN ON OR START
INSTRUMENT CLUSTER
JB-06
JB-10
JB-15
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
MULTIPURPOSE CHECK CONNECTOR (PARTIAL) (BELOW LEFT SIDE OF DASH)
ORG/ WIRE
PASSENGER BUCKLE SWITCH (IN PASSENGER'S SEAT BELT BUCKLE)
PASSENGER PRESENCE DETECTION SENSOR (BELOW RIGHT FRONT SEAT)
PASSENGER SATELLITE SENSOR (NEAR BASE OF RIGHT "B" PILLAR)
PASSENGER SIDE AIRBAG (IN PASSENGER'S SEAT)
PNK WIRE
RED WIRE
STEERING WHEEL)
WHT WIRE
WHT/BLK WIRE
X-02
YEL WIRE
YEL/BLK WIRE
