Starting circuit, a/t early production for Kia Optima II (2005-2008)
Starting circuit, a/t early production
2.4L
A-01
A-02
BATTERY
BATTERY GROUND
BLK WIRE
BURGLAR ALARM RELAY (ON JUNCTION BLOCK)
CLUSTER FUSE
ENGINE COMPARTMENT FUSE/RELAY BOX (AT LEFT SIDE OF ENGINE COMPT)
ENGINE/TRANSAXLE CONTROL MODULE (BEHIND LOWER CENTER OF DASH)
ETACS
FUSE
GRN WIRE
IGNITION SWITCH
INHIBITOR SWITCH (ON TOP OF TRANSAXLE, NEXT TO TRANSAXLE OIL FILTER)
JB-01
JB-01 ENGINE COMPARTMENT FUSE/RELAY BOX (AT LEFT SIDE OF ENGINE COMPT)
JB-02
JB-03
JB-04
JB-05
JB-07
JB-09
JB-16
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LOCK
NCA WIRE
ON OFF
PNK WIRE
RED WIRE
STARTER
STARTER RELAY
W/ BURGLAR ALARM
W/O BURGLAR ALARM
YEL WIRE
