Radio circuit, early production with amplifier for Kia Optima II (2005-2008)
Radio circuit, early production with amplifier
AMPLIFIER (AT RIGHT FRONT OF TRUNK)
ANTENNA
AUDIO
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BRN WIRE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES D/CLOCK FUSE
HOT IN ON OR ACC AUDIO FUSE
J/C 15
JB-01
JB-05
JB-08
JB-09
JB-13
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LEFT FRONT DOOR SPEAKER
LEFT REAR SPEAKER
LEFT TWEETER SPEAKER
NCA WIRE
ORG/ WIRE
P/AMP FUSE
PNK WIRE
POWER ANTENNA SYSTEM
RED WIRE
RIGHT FRONT DOOR SPEAKER
RIGHT REAR SPEAKER
RIGHT TWEETER SPEAKER
WHT WIRE
YEL WIRE
