Electrochromic mirror circuit, late production without home link for Kia Optima II (2005-2008)
Electrochromic mirror circuit, late production without home link
5 5 (2.4L) (2.7L)
BACK UP LAMP SWITCH (2.4L) (ON TOP OF TRANSAXLE) TRANSAXLE RANGE SWITCH (TOP OF
BACK-UP FUSE
BLK WIRE
BLU WIRE
E/R JUNCTION BOX
ELECTRONIC CHROME MIRROR
GRN WIRE
GROUND
HOT IN ON
HOT IN ON OR START
I/P JUNCTION BOX (LEFT END OF DASH)
I/P-L
M/T A/T
MODULE 2 FUSE
ON INPUT
PCB
PNK WIRE
RED WIRE
REVERSE INPUT
TRANSAXLE ASSEMBLY)
WHT WIRE
