Electronic power steering circuit, early production for Kia Optima II (2005-2008)
Electronic power steering circuit, early production
1 2 3 4 5 6 7 8 SOLENOID CTRL SOLENOID CTRL
1 N-03
1 Q-01
2.4L
B-01
BLK WIRE
BRN WIRE
C-01
CRUISE CONTROL UNIT (AT RIGHT REAR CORNER OF ENGINE COMPARTMENT)
DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH)
DIAGNOSIS VSS INPUT ON INPUT GROUND
ELECTRONIC TIME, ALARM CONTROL SYSTEM (ETACS)
EPS FUSE
EPS SOLENOID (ON POWER STEERING RACK HYDRAULIC CONTROL UNIT)
EPS UNIT (BEHIND LOWER CENTER OF DASH)
HOT IN ON
I-01
INSTRUMENT CLUSTER
JB-08 POWER DISTRIBUTION SYSTEM
JB-09
JB-10
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
M/T A/T
SHORT CONNECTOR SC-02
SPEED SENSOR (ON TOP OF TRANSAXLE)
SPEEDOMETER
WHT WIRE
WHT/BLK WIRE
