2.7l, computer data lines circuit, early production for Kia Optima II (2005-2008)
2.7l, computer data lines circuit, early production
ABS CONTROL UNIT (AT RIGHT REAR OF ENGINE COMPARTMENT)
AIR BAG CONTROL UNIT (AT LOWER CENTER OF DASH, ON FLOOR TUNNEL)
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BRN/ORG WIRE
CLUSTER FUSE
DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH)
ENGINE COMPARTMENT FUSE/RELAY BOX (AT LEFT SIDE OF ENGINE COMPT)
ENGINE CONTROL MODULE (BEHIND LOWER CENTER OF DASH)
EPS UNIT (BEHIND LOWER CENTER OF DASH)
FUEL PUMP RELAY (BEHIND RIGHT
FUEL TANK
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
J/C 05
JB-01
JB-06
JB-09
JB-15
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
KEYLESS ENTRY UNIT (BEHIND LOWER CENTER OF DASH)
MULTIPURPOSE CHECK CONNECTOR (BELOW LEFT SIDE OF DASH)
ORG/ WIRE
ORG/BLK WIRE
PNK WIRE
SC-01
SIDE OF DASH)
SUNROOF FUSE
TANK PRESSURE SENSOR (NEAR TOP OF FUEL TANK)
TCM (A/T)
WHT WIRE
WHT/BLK WIRE
YEL WIRE
