Forced entry circuit, early production for Kia Optima II (2005-2008)
Forced entry circuit, early production
BLK WIRE
BLU WIRE
BURGLAR ALARM RELAY (ON JUNCTION BLOCK)
CLUSTER FUSE
D/CLOCK FUSE
DRL FUSE
ETACS
FUSE
GRN WIRE
HAZARD FUSE
HAZARD RELAY (ON JUNCTION BLOCK)
HOOD SWITCH (AT RIGHT FRONT CORNER OF ENGINE COMPARTMENT)
HOT AT ALL TIMES
HOT IN
J/C 05
JB-01
JB-02
JB-02 ENGINE COMPT FUSE/RELAY BOX (AT LEFT SIDE OF ENGINE COMPT)
JB-06
JB-09
JB-13
JUNCTION BLOCK (JB) (BEHIND LEFT SIDE OF DASH)
KEYLESS ENTRY UNIT (BEHIND LOWER CENTER OF DASH)
ORG/ WIRE
ORG/BLK WIRE
PNK WIRE
RED/ORG WIRE
STARTING/ CHARGING SYSTEM
TRUNK UNLOCK SWITCH (AT REAR OF TRUNK)
YEL WIRE
