Car Wiring Diagrams for 2.7l, manual a/c circuit, early production for Kia Optima II (2005-2008)

17 I-01 (A) 3 5 PNK WIRE A/CON FUSE A/CON SW FUSE AIR CON SWITCH B-01 (M) BLK WIRE BLK/ORG WIRE BLOWER FUSE BLOWER MOTOR (BEHIND RIGHT SIDE OF DASH) BLOWER RELAY (BEHIND RIGHT SIDE OF DASH) BLOWER SWITCH BLU WIRE BRN WIRE BRN/ORG WIRE C-01 (C) INSTRUMENT CLUSTER CLUSTER FUSE D/CLOCK FUSE DEFOGGER SYSTEM ENGINE COMPARTMENT FUSE/RELAY BOX (AT LEFT SIDE OF ENGINE COMPARTMENT) ENGINE CONTROL MODULE (ECM) (BEHIND LOWER CENTER OF DASH) ETACS (ON JUNCTION BLOCK) ETACS FUSE GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRY WIRE HIGH LOW HOT AT ALL TIMES HOT AT ALL TIMES JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) HOT IN ON HOT IN ON, START INTAKE ACTUATOR (BEHIND RIGHT END OF DASH) J/C 05 J/C 06 JB-01 JB-02 JB-03 JB-05 JB-09 JB-10 JB-11 MID MODE ACTUATOR (BEHIND CENTER OF DASH) NCA WIRE OFF ORG/ WIRE PNK INTERIOR LIGHTS SYSTEM WIRE PNK PNK 8 9 B-01 (V) 23 B-01 (P) 18 23 24 25 29 40 B-01 (F) 25 24 WIRE PNK PNK WIRE PNK SC-06 WIRE PNK WIRE RED WIRE RESISTOR (BEHIND RIGHT SIDE OF DASH) TEMP ACTUATOR (BEHIND RIGHT SIDE OF DASH) TEMP SWITCH TRIPLE SWITCH (RIGHT FRONT OF ENGINE COMPARTMENT) WHT WIRE YEL WIRE YEL/ORG WIRE

A/CON COMP FUSE AIR CON RELAY BLK WIRE BLU WIRE COMPRESSOR) COND FUSIBLE LINK CONDENSER FAN HIGH RELAY 1 CONDENSER FAN HIGH RELAY 2 CONDENSER FAN LOW RELAY CONDENSER FAN MOTOR (BEHIND RIGHT SIDE OF RADIATOR) COOLING FAN HIGH RELAY 1 COOLING FAN HIGH RELAY 2 COOLING FAN LOW RELAY COOLING FAN MOTOR (BEHIND LEFT SIDE OF RADIATOR) EGR FUSE ENGINE COMPARTMENT FUSE/RELAY BOX (AT LEFT SIDE OF ENGINE COMPARTMENT) GRN WIRE GRN/ORG WIRE GRY WIRE HOT AT ALL TIMES JB-02 JB-03 JC-07 MAIN FUSE MAIN RELAY (BEHIND RIGHT SIDE OF DASH ORG/ WIRE PNK WIRE RAD FUSIBLE LINK RED WIRE THERMISTOR (BEHIND RIGHT SIDE OF DASH) WHT WIRE YEL WIRE
