Kia Optima II (2005-2008) speed sig a/c relay control fan rly ctrl cruise ind cruise ind ccv mil ind Wiring diagram
This page shows the only wiring diagram for the component.speed sig a/c relay control fan rly ctrl cruise ind cruise ind ccv mil ind, which is found in the car Kia Optima II (2005-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram speed sig a/c relay control fan rly ctrl cruise ind cruise ind ccv mil ind (1 of 1)
AIR CONDITIONING SYSTEM COOLING FANS SYSTEM
ANTI-LOCK BRAKES SYSTEM
ANTI-THEFT SYSTEM
APS 2 SUPPLY SENSOR SUPPLY
B/UP FUSE
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
COOLING FANS SYSTEM
CRUISE CONTROL SYSTEM
CYL 1& 4
ECU 1 FUSE
ECU RLY FUSIBLE LINK
ENGINE CONTROL RELAY
ENGINE ROOM JUNCTION BOX
ETC MOTOR, THROTTLE POSITION SENSOR (ON THROTTLE BODY)
F/PUMP FUSE
FUEL INJ +
FUEL PUMP RELAY
FUEL SENDER, FUEL PUMP MOTOR (TOP OF FUEL TANK)
GRN WIRE
GRN/ORG WIRE
HOT AT ALL TIMES
HOT IN ON OR START
I/P-D
I/P-E
INSTRUMENT CLUSTER MIL IND
INSTRUMENT PANEL JUNCTION BOX (LEFT END OF DASH)
PCM (LEFT REAR OF ENGINE COMPT)
PNK WIRE
POWER STEERING SWITCH (ON POWER STEERING OIL PUMP)
RED WIRE
SNSR 3 FUSE
SPEED SIG A/C RELAY CONTROL FAN RLY CTRL CRUISE IND CRUISE IND CCV MIL IND
STOP LAMP SWITCH (ABOVE BRAKE PEDAL, ON BRACKET)
STOP LP FUSE
TACHOMETER
THROTTLE POSITION SENSOR
TO IGN COIL
TO SNSR 1
WHT WIRE
YEL/BLK WIRE
