Kia Optima II (2005-2008) select sw Wiring diagram
This page shows the only wiring diagram for the component.select sw, which is found in the car Kia Optima II (2005-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram select sw (1 of 1)
3 1 2 PULSE GENERATOR A (ON TOP OF TRANSAXLE)
3 2 1 PULSE GENERATOR B (ON TOP OF TRANSAXLE)
A/C REQ SW
AIR CONDITIONING SYSTEM
ALT (ER)
ATM CONTROL RELAY
ATM CTRL RLY
ATM FUSE
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/ORG WIRE
BRAKE SW
CAM SENSOR
CAMSHAFT POSITION SENSOR 2 (ON REAR OF
CAN HIGH
CAN LOW
CLUTCH IN
COMPUTER DATA LINES SYSTEM
CPS HIGH
CRUISE CONTROL SYSTEM
CRUISE SW
CRUISE SW GND
D INPUT
ECT SENSOR
ECU FUSE
ENGINE ROOM JUNCTION BOX
ETC MTR SIG
FROM SNSR 1
FROM SNSR 2
GRN WIRE
GRN/ORG WIRE
GROUND
HOT AT ALL TIMES
HOT IN ON OR START
IGN COIL 6
IGN COIL FUSE
INPUT
MAP SIGNAL
N INPUT
NCA WIRE
OIL TEMP SENS
OIL TEMP SENSOR
ON/START IN
ORG/ WIRE
OUTPUT
P INPUT
PCM (LEFT REAR OF ENGINE COMPT) POWER STEERING SWITCH (AT FRONT OF ENGINE)
PCU FUSE
PNK 11 12 13 14 15 16 17 18 19 WIRE
PNK 7 8 WIRE
PNK WIRE
R INPUT
RED WIRE
SELECT SW
SENSOR GND
SHIELD GND
SNSR 3 FUSE
STARTING/ CHARGING SYSTEM
SW INPUT
TPS 1 GROUND
TPS 1 POWER
TPS 2 SUPPLY
UP SHIFT
WHT WIRE
YEL/ORG WIRE
Go to component -> Wiring diagram engine performance 2.7l, late production (4 of 5) -> SELECT SW
