Kia Optima II (2005-2008) right stop light left stop light Wiring diagram
This page shows the only wiring diagram for the component.right stop light left stop light, which is found in the car Kia Optima II (2005-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right stop light left stop light (1 of 1)
BATTERY JOINT CONNECTOR
BLK WIRE
CLOCKSPRING/ COMBINATION SWITCH
COMBINATION SWITCH
CRUISE CONTROL UNIT
CRUISE REMOTE CONTROL SWITCH
DRIVER POWER SEAT ABS CONTROL UNIT
ETACS
FUSE/RELAY BOX COOLING FAN LOW RELAY WIPER RELAY
GRN WIRE
GROUND
HIGH MOUNT STOP LIGHT FUEL LID ACTUATOR
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER AMPLIFIER
J/C 14
JB-07
JOINT CONNECTOR JC-05
JOINT CONNECTOR JC-07
JOINT CONNECTOR JC-08
JOINT CONNECTOR JC-15
JOINT CONNECTOR JC-17
LEFT FRONT DOOR KEY UNLOCK SWITCH
LEFT FRONT FOGLIGHT
LEFT FRONT TURN SIGNAL LAMP
LEFT HIGH HEADLIGHT
LEFT HORN
LEFT LICENSE LAMP RIGHT LICENSE LAMP RIGHT TAILLAMP
LEFT LOW HEADLIGHT
LEFT POSITION LAMP
LEFT POWER MIRROR MOTOR LEFT FRONT DOOR LOCK MOTOR
LEFT REAR COMBINATION LAMP
LEFT REAR TURN SIGNAL LAMP
LEFT SEAT WARMER
LEFT SIDE MARKER LAMP
MAP LAMP ROOM LAMP OVERHEAD CONSOLE
NCA WIRE
ORG/ WIRE
PASSENGER POWER SEAT SEAT BELT SWITCH
POWER ANTENNA
POWER MIRROR SWITCH
REAR DEFROSTER RELAY
RIGHT FRONT FOGLIGHT
RIGHT FRONT TURN SIGNAL LAMP
RIGHT HIGH HEADLIGHT
RIGHT LEFT SUNVISOR LAMP SUNVISOR LAMP
RIGHT LOW HEADLIGHT
RIGHT POSITION DRL UNIT RIGHT HORN LAMP
RIGHT REAR COMBINATION LAMP
RIGHT REAR TURN SIGNAL LEFT TAILLAMP LAMP
RIGHT SIDE MARKER LAMP
RIGHT STOP LIGHT LEFT STOP LIGHT
RIGHT TAILLAMP TRUNK LID SOLENOID
SUN ROOF RELAY
SUN-ROOF MOTOR
TRUNK UNLOCK SWITCH LEFT TAILLAMP
TWO TURN UNLOCK RELAY
W/ ABS
W/O ABS
W/O SUN ROOF
W/O SUN ROOF W/ SUN ROOF
Go to component -> Ground distribution circuit, early production (1 of 3) -> RIGHT STOP LIGHT LEFT STOP LIGHT
