Kia Optima II (2005-2008) right low headlamp Wiring diagrams
This page contains all the electrical diagrams for the component. right low headlamp, in which he is found in the car Kia Optima II (2005-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right low headlamp (1 of 2)
1 2 3 4 5 6 PNK WIRE
AUTO LIGHT CONTROL UNIT (UNDER CENTER OF DASH)
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BRN WIRE
C-01
CLUSTER FUSE
COMB- INATION SWITCH LO HI PASS
DIODE (UNDER LEFT SIDE OF DASH)
E-01
ENGINE COMPARTMENT FUSE/RELAY BOX (AT LEFT SIDE OF ENGINE COMPT)
ETACS
FOG FUSE
FOG LAMP SWITCH
FRONT FOGLAMP RELAY
GRN WIRE
GRY WIRE
HEAD FUSE
HEAD HI FUSE
HEAD LOW FUSE
HEAD- LIGHT RELAY (HIGH)
HEADLIGHT RELAY (LOW)
HIGH BEAM IND
HOT AT ALL TIMES
HOT IN ON
HOT IN ON OR START
ILLUM- INATION SWITCH
INSTRUMENT CLUSTER FRONT FOG- LAMP IND
J/C 05
J/C 06
J/C-07 J/C-08
JB-01
JB-02
JB-05
JB-09
JB-11
JC-07
JC-08
JUNCTION BLOCK (JB) (BEHIND LEFT SIDE OF DASH)
LEFT HIGH HEADLAMP
LEFT LOW HEADLAMP
LO HI
LO HI PASS PASS
OFF
OFF AUTO
OFF AUTO AUTO
ORG/ WIRE
PNK E-01 WIRE
PNK PNK WIRE
PNK WIRE
RIGHT FRONT FOG LAMP LEFT FRONT FOG LAMP
RIGHT HIGH HEADLAMP
RIGHT LOW HEADLAMP
RIGHT TAIL FUSE
SC-06
TAIL FUSE
TAILLAMP RELAY
WHT WIRE
YEL WIRE
Go to component -> Headlights circuit, early production with autolamps -> RIGHT LOW HEADLAMP
Wiring diagram right low headlamp (2 of 2)
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
C-01
COMBINATION SWITCH LO HI
DIODE (UNDER LEFT SIDE OF DASH)
E-01
ENGINE COMPARTMENT FUSE/RELAY BOX (AT LEFT SIDE OF ENGINE COMPT)
ETACS
FOG FUSE
FRONT FOG LAMP IND
FRONT FOG LAMP RELAY
FRONT FOG- LAMP SWITCH OFF
GRN WIRE
GRY WIRE
HEAD FUSE
HEAD HI FUSE
HEAD LOW FUSE
HEADLIGHT RELAY (HIGH)
HEADLIGHT RELAY (LOW)
HIGH BEAM IND
HOT AT ALL TIMES
HOT IN ON
ILLUMINATION SWITCH
INSTRUMENT CLUSTER
J/C 05
J/C 06
J/C-07 J/C-08
JB-01
JB-02
JB-05
JB-09
JC-07
JC-08
JUNCTION BLOCK (JB) (BEHIND LEFT SIDE OF DASH)
LEFT HIGH HEADLAMP LEFT LOW HEADLAMP
LO LO HI PASS HI PASS
OFF
ORG/ WIRE
PASS
PNK E-01 WIRE
PNK WIRE
RIGHT FRONT FOG LAMP LEFT FRONT FOG LAMP
RIGHT HIGH HEADLAMP
RIGHT LOW HEADLAMP
RIGHT TAIL FUSE
TAIL FUSE
TAILLAMP RELAY
WHT WIRE
YEL WIRE
Go to component -> Headlights circuit, early production without drl -> RIGHT LOW HEADLAMP
