Kia Optima II (2005-2008) power memory Wiring diagram
This page shows the only wiring diagram for the component.power memory, which is found in the car Kia Optima II (2005-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram power memory (1 of 1)
5 5 (2.4L) (2.7L)
BACK-UP FUSE
BACK-UP LAMP SWITCH (ON TOP OF TRANSAXLE)
BLK WIRE
BLU WIRE
ELECTRONIC CHROME MIRROR CONTROL
ENGINE ROOM JUNCTION BOX
GRN WIRE
HL 1
HL 2
HL 3
HOME LINK
HOT AT ALL TIMES
HOT IN ON
HOT IN ON OR START
I/P JUNCTION BOX (LEFT END OF DASH)
I/P-J
I/P-L
M/T A/T
MEMORY FUSE
MODULE 2 FUSE
ON INPUT
ON OFF
PNK WIRE
POWER CONNECTOR
POWER MEMORY
RED WIRE
REVERSE
TRANSAXLE ASSEMBLY)
TRANSAXLE RANGE SWITCH (TOP OF
WHT WIRE
YEL WIRE
Go to component -> Electrochromic mirror circuit, late production with home link -> POWER MEMORY
