Kia Optima II (2005-2008) overhead console Wiring diagrams
This page contains all the electrical diagrams for the component. overhead console, in which he is found in the car Kia Optima II (2005-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
overhead console wiring diagram (1 of 5)
Go to component -> Courtesy lamps circuit, early production with sunroof -> OVERHEAD CONSOLE
overhead console wiring diagram (2 of 5)
Go to component -> Courtesy lamps circuit, late production -> OVERHEAD CONSOLE
overhead console wiring diagram (3 of 5)
Go to component -> Ground distribution circuit, late production (3 of 3) -> OVERHEAD CONSOLE
overhead console wiring diagram (4 of 5)
Go to component -> Power top/sunroof circuit, early production -> OVERHEAD CONSOLE
overhead console wiring diagram (5 of 5)
Go to component -> Power top/sunroof circuit, late production -> OVERHEAD CONSOLE
