Kia Optima II (2005-2008) mem pwr b-01 Wiring diagram
This page shows the only wiring diagram for the component.mem pwr b-01, which is found in the car Kia Optima II (2005-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mem pwr b-01 (1 of 1)
1 8 PNK WIRE
10 11 12 13 14 15 16 17 PNK WIRE
A/C PRES
AIR CONDITIONING SYSTEM
AIR FLOW SENS CMP SENS SENS GROUND P/N INPUT
AIR TEMP SENS
B-01
BLK WIRE
BLU WIRE
BRN WIRE
BRN/ORG WIRE
CHECK ENGINE IND
CLOSE
CLUSTER FUSE
CONDENSER (ON REAR OF ENGINE)
COOLING FANS SYSTEM
DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH)
ECM CONTROL RELAY (BEHIND RIGHT SIDE OF DASH)
EGR SOL
ENGINE COMPARTMENT FUSE/RELAY BOX (AT LEFT SIDE MAIN FUSE
ENGINE/TRANSAXLE CONTROL MODULE (BEHIND LOWER CENTER OF DASH)
F PMP CTRL A/C REL MIL CTRL SPARK TIMING INJ 3
FAN RLY FAN RLY
FUEL INJECTORS
FUEL PUMP
FUEL TANK
GEN FR INJ 2
GRN WIRE
GRN/ORG WIRE
GRY WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES ECU FUSE
HOT IN ON OR START
IGN COIL 1 IGN COIL 2 PNK WIRE
IGNITION COIL 1 (AT TOP REAR OF ENGINE)
IGNITION FAILURE SENSOR (ON REAR OF ENGINE)
IGNITION SWITCH
INJ 1 INJ 4
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER SYSTEM
JB-03
JB-07 JUNCTION BLOCK (JB) (BEHIND LEFT SIDE OF DASH)
JB-11
JUNCTION BLOCK (JB) (BEHIND LEFT SIDE OF DASH)
LOCK OFF ON
MEM PWR B-01
NCA WIRE
OF ENGINE COMPT) JB-03
ORG/ WIRE
PNK FUEL LVL WIRE
PNK PNK PNK PNK PNK PNK PNK 1 2 3 4 5 6 7 8 9 WIRE
PNK PNK WIRE
PNK WIRE
POWER STEERING SWITCH (ON POWER STEERING OIL PUMP)
PURGE SOL CCV
PURGE SOLENOID VALVE (ON TOP RIGHT SIDE OF ENGINE)
RED WIRE
SC-06
STARTING/ CHARGING SYSTEM
TO SPARK PLUGS
WHT WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Wiring diagram engine performance 2.4l, a/t early production (1 of 4) -> MEM PWR B-01
