Kia Optima II (2005-2008) main relay (behind right side of dash Wiring diagrams

This page contains all the electrical diagrams for the component. main relay (behind right side of dash, in which he is found in the car Kia Optima II (2005-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

main relay (behind right side of dash wiring diagram (1 of 3)

Kia Optima II (2005-2008) main relay (behind right side of dash wiring diagram (1 of 3)

A/CON COMP FUSE AIR CON RELAY BLK WIRE BLU WIRE BRN WIRE COMPRESSOR) COND FUSIBLE LINK CONDENSER FAN HIGH RELAY 1 CONDENSER FAN HIGH RELAY 2 CONDENSER FAN LOW RELAY CONDENSER FAN MOTOR (BEHIND RIGHT SIDE OF RADIATOR) COOLING FAN HIGH RELAY 1 COOLING FAN HIGH RELAY 2 COOLING FAN LOW RELAY COOLING FAN MOTOR (BEHIND LEFT SIDE OF RADIATOR) EGR FUSE ENGINE COMPARTMENT FUSE/RELAY BOX (AT LEFT SIDE OF ENGINE COMPARTMENT) ENGINE COMPARTMENT FUSE/RELAY BOX (AT LEFT SIDE OF ENGINE COMPARTMENT) JB-01 GRN WIRE GRN/ORG WIRE GRY WIRE HOT AT ALL TIMES JB-01 JB-02 JB-03 JC-07 MAIN FUSE MAIN RELAY (BEHIND RIGHT SIDE OF DASH MID ORG/ WIRE PNK WIRE RAD FUSIBLE LINK RED WIRE TRIPLE SWITCH (RIGHT FRONT OF ENGINE COMPARTMENT) WHT WIRE WIPER/ WASHER SYSTEM YEL WIRE

Go to component -> 2.7l, automatic a/c circuit, early production (2 of 2) -> MAIN RELAY (BEHIND RIGHT SIDE OF DASH

main relay (behind right side of dash wiring diagram (2 of 3)

Kia Optima II (2005-2008) main relay (behind right side of dash wiring diagram (2 of 3)

A/CON COMP FUSE AIR CON RELAY BLK WIRE BLU WIRE COMPRESSOR) COND FUSIBLE LINK CONDENSER FAN HIGH RELAY 1 CONDENSER FAN HIGH RELAY 2 CONDENSER FAN LOW RELAY CONDENSER FAN MOTOR (BEHIND RIGHT SIDE OF RADIATOR) COOLING FAN HIGH RELAY 1 COOLING FAN HIGH RELAY 2 COOLING FAN LOW RELAY COOLING FAN MOTOR (BEHIND LEFT SIDE OF RADIATOR) EGR FUSE ENGINE COMPARTMENT FUSE/RELAY BOX (AT LEFT SIDE OF ENGINE COMPARTMENT) GRN WIRE GRN/ORG WIRE GRY WIRE HOT AT ALL TIMES JB-02 JB-03 JC-07 MAIN FUSE MAIN RELAY (BEHIND RIGHT SIDE OF DASH ORG/ WIRE PNK WIRE RAD FUSIBLE LINK RED WIRE THERMISTOR (BEHIND RIGHT SIDE OF DASH) WHT WIRE YEL WIRE

Go to component -> 2.7l, manual a/c circuit, early production (2 of 2) -> MAIN RELAY (BEHIND RIGHT SIDE OF DASH

main relay (behind right side of dash wiring diagram (3 of 3)

Kia Optima II (2005-2008) main relay (behind right side of dash wiring diagram (3 of 3)

AIR TEMPERATURE SENSOR (ON INTAKE MANIFOLD) B-01 BLK WIRE BLK/ORG WIRE BLU WIRE BRN WIRE CKP SIGNAL ECM RELAY ECU FUSE ENGINE COMPARTMENT FUSE/RELAY BOX (AT LEFT SIDE ENGINE CONTROL MODULE (BEHIND LOWER CENTER OF DASH) ENGINE COOLANT TEMPERATURE SENSOR (AT TOP REAR OF ENGINE) FUEL INJECTORS GRN WIRE GRN/ORG WIRE HOT AT ALL TIMES IGNITION IGNITION SWITCH JB-03 K-LINE GROUND GROUND GROUND MEM PWR BATTERY BATTERY LOCK OFF ON MAF SENS GRD MAF SIGNAL MAIN FUSE MAIN RELAY (BEHIND RIGHT SIDE OF DASH NCA WIRE OF ENGINE COMPT) OPENING CLOSING GROUND ORG/ WIRE PCSV CNTRL PNK PNK PNK PNK PNK 2 3 4 5 6 7 8 WIRE PNK PNK WIRE PNK WIRE POWER POWER STEERING SWITCH (ON POWER STEERING OIL PUMP) PURGE SOLENOID VALVE (ON TOP RIGHT SIDE OF ENGINE) RED WIRE STARTING/ CHARGING SYSTEM WHT WIRE YEL WIRE YEL/ORG WIRE

Go to component -> Wiring diagram engine performance 2.7l, early production (1 of 4) -> MAIN RELAY (BEHIND RIGHT SIDE OF DASH
