Kia Optima II (2005-2008) lo int off hi Wiring diagrams
This page contains all the electrical diagrams for the component. lo int off hi, in which he is found in the car Kia Optima II (2005-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
lo int off hi wiring diagram (1 of 2)
14 15 PNK WASHER SIG INT WIRE
BCM (UNDER LEFT SIDE OF DASH)
BLK WIRE
BLU WIRE
BRN WIRE
CLUSTER FUSE
DELAY CONTROL
E/R JUNCTION BOX
GRN WIRE
HI OFF LO INT
HOT IN ON
HOT IN ON OR START
I/P JUNCTION BOX (LEFT END OF DASH)
I/P-C
I/P-E
I/P-K
INSTRUMENT CLUSTER
INT TIME
JOINT CONNECTOR
LO INT HI OFF
LO INT OFF HI
MIST SWITCH
MULTI- FUNCTION SWITCH
ORG/ WIRE
PNK WIRE
PNK/BLK WIRE
RED WIRE
WASHER LEVEL SENSOR (IN WASHER FLUID RESERVOIR, IN RIGHT FRONT WHEEL WELL)
WASHER MOTOR (AT RIGHT FRONT OF ENGINE COMPT)
WASHER SWITCH
WHT WIRE
WIPER CONTROL
WIPER FUSE
WIPER MOTOR (ON LEFT SIDE OF FIREWALL)
WIPER RELAY
WIPER SWITCH
YEL WIRE
YEL/BLK WIRE
YEL/ORG WIRE
Go to component -> Front wiper/washer circuit, late production without rain sensor -> LO INT OFF HI
lo int off hi wiring diagram (2 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
COMBINATION SWITCH
D-01
ENGINE COMPARTMENT FUSE/RELAY BOX (AT LEFT SIDE OF ENGINE COMPT)
ETACS (ON JUNCTION BLOCK)
GRN WIRE
GRY WIRE
HOT IN ON
J/C 05
JB-01
JB-01 ENGINE COMPARTMENT FUSE/RELAY BOX (AT LEFT SIDE OF ENGINE COMPT)
JB-02
JB-03
JB-05
JC-07
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LO INT
LO INT HI OFF
LO INT OFF HI
MIST
MIST SWITCH
OFF
PARK
PNK WIRE
WASHER MOTOR (AT RIGHT FRONT OF ENGINE COMPT)
WASHER SWITCH
WIPER FUSE
WIPER MOTOR (ON LEFT SIDE OF FIREWALL)
WIPER RELAY
WIPER SWITCH
YEL WIRE
Go to component -> Wiper/washer circuit, early production -> LO INT OFF HI
