Kia Optima II (2005-2008) icm relay box (left side Wiring diagram
This page shows the only wiring diagram for the component.icm relay box (left side, which is found in the car Kia Optima II (2005-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram icm relay box (left side (1 of 1)
AUTO HI OFF
AUTO OFF HI
BLK WIRE
BLU/BLK WIRE
BLU/ORG WIRE
CLUSTER FUSE
DELAY CONTROL
E/R JUNCTION BOX
GRN WIRE
GRN/ORG WIRE
GRY WIRE
HOT IN ON
HOT IN ON OR START
I/P JUNCTION BLOCK (LEFT END OF DASH)
I/P-B
I/P-C
I/P-E
I/P-K
I/P-L
ICM RELAY BOX (LEFT SIDE
INSTRUMENT CLUSTER
JOINT CONNECTOR
MIST SWITCH
MODULE 2 FUSE
MULTI- FUNCTION SWITCH
OF DASH)
OFF LO AUTO
ORG/ WIRE
PNK WIRE
PNK/BLK WIRE
RAIN SENSOR (FOREWORD OF OVERHEAD CONSOLE)
RAIN SENSOR RELAY
RED WIRE
WASHER LEVEL SENSOR (IN WASHER FLUID RESERVOIR, IN RIGHT FRONT WHEEL WELL)
WASHER MOTOR (AT RIGHT FRONT OF ENGINE COMPT)
WASHER SWITCH
WHT WIRE
WHT/BLK WIRE
WIPER FUSE
WIPER MOTOR (ON LEFT SIDE OF FIREWALL)
WIPER RELAY
WIPER SWITCH
YEL WIRE
YEL/BLK WIRE
YEL/ORG WIRE
Go to component -> Front wiper/washer circuit, late production with rain sensor -> ICM RELAY BOX (LEFT SIDE
