Kia Optima II (2005-2008) ground ground atm ctrl Wiring diagram

ATM CONTROL RELAY ATM FUSE ATM SOLENOID (TOP OF TRANSAXLE ASSEMBLY) BLK WIRE BLU WIRE BLU/ORG WIRE BOX (LEFT END OF DASH) BRN WIRE COMPT) DCC VFS GROUND ENGINE ROOM JUNCTION BOX GRN WIRE GRN/ORG WIRE GROUND GROUND ATM CTRL GRY WIRE HOT AT ALL TIMES I/P JUNCTION I/P-D OIL TEMP SENS SENS GROUND PULSE GEN B OIL TEMP SENSOR ORG/ WIRE P INPUT R INPUT N INPUT D INPUT SELECT SWITCH UP SHIFT DOWN SHIFT PCM (LEFT REAR OF ENGINE PNK LR 5 SPEED TM UD BATT VOLTAGE BATT VOLTAGE PWM SIGNAL WIRE PNK PULSE GEN A WIRE PNK WIRE RED WIRE STOP LAMP FUSE STOP LAMP SW STOP LAMP SWITCH (ABOVE BRAKE PEDAL, ON BRACKET) TRANSAXLE CONTROL MODULE (LEFT REAR OF ENGINE COMPARTMENT) WHT WIRE YEL WIRE YEL/ORG WIRE
