Kia Optima II (2005-2008) front height adjuster (below Wiring diagram
This page shows the only wiring diagram for the component.front height adjuster (below, which is found in the car Kia Optima II (2005-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front height adjuster (below (1 of 1)
BACK
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
DOWN
FORWARD/
FRONT HEIGHT ADJUSTER (BELOW
HOT AT ALL TIMES
JB-08
JOINT CONNECTOR JC-14
JOINT CONNECTOR JC-15
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LT GRN/BLK WIRE
LT GRN/WHT WIRE
ORG/ WIRE
P/SEAT FUSE (PASSENGER)
PASSENGER POWER SEAT ADJUSTER SWITCH
PASSENGER'S SEAT)
REAR HEIGHT ADJUSTER
RECLINING ADJUSTER (BELOW PASSENGER'S SEAT)
RED/BLK WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
SLIDE ADJUSTER
SLIDE ADJUSTER LIMIT SWITCH
WHT/BLK WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> Passenger seat circuit, early production -> FRONT HEIGHT ADJUSTER (BELOW
