Kia Optima II (2005-2008) etc motor, throttle position sensor wiring diagram
This page shows the only wiring diagram for the component.etc motor, throttle position sensor, which is found in the car Kia Optima II (2005-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
etc motor, throttle position sensor wiring diagram (1 of 1)
76 25 BATTERY VOLTAGE CRUISE CONTROL SWITCH
BACK-UP FUSE
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
CLOCK- SPRING
CRUISE CONTROL SWITCH (GND) BRAKE TEST SWITCH BRAKE LIGHT SWITCH
CRUISE IND
CRUISE MAIN
CRUISE SET IND
E/R JUNCTION BOX
ECU FUSE
ETC MOTOR, THROTTLE POSITION SENSOR
GRN WIRE
GRN/ORG WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
HOT IN ON OR START
ILL
INSTRUMENT CLUSTER
JOINT CONNECTOR
MULTI- FUNCTION
PCM (LEFT REAR OF ENGINE COMPARTMENT)
PNK PNK WIRE
PNK WIRE
PNK/BLK WIRE
RED WIRE
RESUME/ ACCEL
RIGHT CRUISE REMOCON SWITCH
SET/ COAST
STEERING WHEEL)
SWITCH
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> 2.7l, cruise control circuit, late production (1 of 2) -> ETC MOTOR, THROTTLE POSITION SENSOR
