Kia Optima II (2005-2008) drl unit Wiring diagrams
This page contains all the electrical diagrams for the component. drl unit, in which he is found in the car Kia Optima II (2005-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram drl unit (1 of 2)
A/CON FUSE
ABS 1 FUSE
ABS 2 FUSE
ABS CONTROL UNIT
ACC SOCKET
ACC SOCKET FUSE
AIR CON CONTROL UNIT
ALT FUSIBLE LINK
AUDIO
AUDIO FUSE
AUTOMATIC A/C
BATTERY
BLK WIRE
BRN WIRE
C/LIGHTER FUSE
CIGAR LIGHTER
COND FUSE
CONDENSER FAN HIGH RELAY 2
CONDENSER FAN MOTOR
COOLING FAN HIGH RELAY 2
COOLING FAN MOTOR
CRUISE CONTROL SWITCH EPS UNIT
DRL UNIT
ENGINE COMPARTMENT FUSE/RELAY BOX (AT LEFT SIDE OF ENGINE COMPARTMENT)
EPS FUSE
FROM JOINT CONNECTOR SC-02 (DIAGRAM 3 OF 5)
FUSE
GENERATOR
HEAD FUSE
HEADLIGHT HIGH RELAY
HEADLIGHT LOW RELAY
IGNITION SWITCH
JB-01
JB-01 AIR CON SWITCH
JB-02
JB-03
JB-04
JB-05
JB-06
JB-07
JB-08
JB-09
JB-09 MANUAL A/C
JB-11
JB-16
JOINT CONNECTOR JC-05
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LOCK
MODE ACTUATOR
NCA WIRE
ON LOCK OFF
ON OFF
ORG/ WIRE
P/WINDOW FUSE
PNK WIRE
POWER MIRROR SWITCH
POWER WINDOW RELAY
RAD FUSE
RED WIRE
STARTER
STARTER RELAY
TO BLOWER FUSE (DIAGRAM 2 OF 5)
TO ETACS FUSE (DIAGRAM 5 OF 5)
TO JUNCTION BLOCK (BACK-UP FUSE) (DIAGRAM 2 OF 5)
TO JUNCTION BLOCK (START FUSE) (DIAGRAM 5 OF 5)
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit, early production (1 of 5) -> DRL UNIT
Wiring diagram drl unit (2 of 2)
2.4L
2.7L 2 3
4 OF 5)
A/T M/T
ATM CONTROL RELAY (2.4L) A/T CONTROL RELAY (2.7L)
ATM FUSE
BLU WIRE
BRN WIRE
BRN/ORG WIRE
BRN/WHT WIRE
DIGITAL CLOCK
DRL FUSE
DRL UNIT
ECU FUSE
ENGINE/ TRANSAXLE CONTROL MODULE ENGINE CONTROL MODULE
FOG FUSE
FROM MAIN FUSE (DIAGRAM 2 OF 5)
FRONT FOG LAMP RELAY
FUEL PUMP FUSE
FUEL PUMP RELAY
GENERATOR
GRN WIRE
HEAD HI FUSE
HEAD LOW FUSE
HEADLIGHT HIGH RELAY
HEADLIGHT LOW RELAY
INSTRUMENT CLUSTER
JB-01
JB-02
JB-03
JB-03 JB-02
JB-05
JB-06
JB-06 PNK WIRE
JB-09
JB-13
JB-13 JB-11
JOINT CONNECTOR JC-06
JOINT CONNECTOR SC-02
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LEFT SEAT WARMER SWITCH ATM ILLUMINATION
LEFT SIDE MARKER LAMP LEFT POSITION LAMP
LEFT TAIL LAMP LEFT LICENSE LAMP LEFT TAIL LAMP
LH TAIL FUSE
MANUAL A/C AUTOMATIC A/C
ORG/ WIRE
PNK JB-08 WIRE
PNK PNK PNK PNK WIRE
PNK PNK PNK WIRE
PNK PNK WIRE
PNK WIRE
POWER WINDOW MAIN SWITCH RIGHT FRONT POWER WINDOW SWITCH
RED WIRE
RH TAIL FUSE
RIGHT POSITION LAMP
RIGHT SEAT WARMER SWITCH
RIGHT SIDE MARKER LAMP
RIGHT TAIL LAMP
RIGHT TAIL LAMP RIGHT LICENSE LAMP
SIREN
SPORTS MODE SWITCH AIR CON SWITCH AIR CON CONTROL UNIT
TAIL FUSE
TAIL LAMP RELAY
TCM (2.7L)
TCS SWITCH PANEL LIGHT CONTROL SWITCH GLOVE BOX LAMP HAZARD SWITCH
TO CIGAR LIGHTER (DIAGRAM 1 OF 5)
TO POWER FUSE 1 (DIAGRAM
Go to component -> Power distribution circuit, early production (3 of 5) -> DRL UNIT
