Kia Optima II (2005-2008) driver seat driver cushion warmer module warmer wiring diagram
This page shows the only wiring diagram for the component.driver seat driver cushion warmer module warmer, which is found in the car Kia Optima II (2005-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
driver seat driver cushion warmer module warmer wiring diagram (1 of 1)
BLK WIRE
DRIVER DOOR LOCK ACTUATOR
DRIVER DOOR UNLOCK SWITCH
DRIVER OUTSIDE MIRROR MOTOR, DEFOGGER
DRIVER RECLINING DRIVER RECLINING
DRIVER SEAT DRIVER CUSHION WARMER MODULE WARMER
DRIVER SEAT MANUAL SWITCH
DRIVER SIDE
ELECTRONIC CHROME MIRROR
FUEL FILLER ACTUATOR
FUEL FILLER DOOR, TRUNK LID SWITCH
HIGH MOUNTED
HOME LINK
J/C
LEFT "C" PILLAR)
LEFT LICENSE LAMP
LEFT REAR COMBINATION LAMP (OUT)
LEFT REAR DOOR LOCK ACTUATOR
LEFT REAR POWER WINDOW SWITCH
LEFT VANITY LAMP
LIMIT SWITCH
NCA WIRE
OVERHEAD CONSOLE
POWER OUTSIDE MIRROR SWITCH
POWER WINDOW MAIN SWITCH
RAIN SENSOR
RIGHT LICENSE LAMP
RIGHT REAR COMBINATION LAMP (IN)
RIGHT VANITY LAMP
ROOM LAMP
SAFETY WINDOW MOTOR
STOP LAMP
SUNROOF CONTROL MODULE
TRUNK LEFT REAR UNLOCK COMBINATION SWITCH LAMP (IN)
TRUNK LID MOTOR
WARMER LIMIT SWITCH
Go to component -> Ground distribution circuit, late production (3 of 3) -> DRIVER SEAT DRIVER CUSHION WARMER MODULE WARMER
